Connecting Rod for Diesel Engines: Weichai, Baudouin and Yuchai
A connecting rod transfers the firing impulse from the piston to the crankshaft, and its big end carries the highest alternating load of any bearing in a diesel engine. Because the rod is a matched assembly rather than a single part, buying the right one depends on the rod number, the piston pin diameter and the weight class of the set. Connecting rod part numbers by engine The table below lists the rod assemblies we hold for the Weichai, Baudouin and Yuchai families. Use the engine plate and the old rod number together — two rods can share a length and big end diameter and still differ in weight class. BrandEnginePart numberProduct page Baudouin4M10G1004743018Baudouin 4M10G Connecting Rod 1004743018 Marine Diesel PartsWeichaiWD615E261500030009Weichai Connecting Rod Kit WD615E2 61500030009WeichaiWP13612630020017Weichai WP13 Connecting Rod 612630020017 Diesel Engine PartsWeichaiWP612160519Weichai WP6 Connecting Rod 12160519 Diesel Engine PartsWeichaiWP7610800030073Weichai WP7 WP8 Connecting Rod 610800030073 Diesel Engine PartsWeichaiWP9611600030017Weichai WP9 Connecting Rod 611600030017 Diesel Engine Parts What decides fitment Three dimensions decide whether a rod will work, and all three are measurable: Big end bore — must match the bearing shell and the journal after any regrind. Small end bush diameter — must match the piston pin; a worn bush loads...
